Problem Statement
Red Hat Enterprise Linux (RHEL) 7 fully supports IPv6 network. It is not much difficult to configure an IPv6 network, if you have some basic understanding of IPv6 addressing scheme.
In this article, we will configure Linux IPv6 Networking between two Red Hat Enterprise Linux (RHEL) 7 machines by setting static IPv6 addresses using nmcli commands.
What is IPv6?
Internet Protocol version 6 (IPv6) is the most recent version of the Internet Protocol (IP), the communications protocol that provides an identification and location system for computers on networks and routes traffic across the Internet. IPv6 was developed by the Internet Engineering Task Force (IETF) to deal with the long-anticipated problem of IPv4 address exhaustion, and is intended to replace IPv4. In December 1998, IPv6 became a Draft Standard for the IETF, which subsequently ratified it as an Internet Standard on 14 July 2017.
Devices on the Internet are assigned a unique IP address for identification and location definition. With the rapid growth of the Internet after commercialization in the 1990s, it became evident that far more addresses would be needed to connect devices than the IPv4 address space had available. By 1998, the IETF had formalized the successor protocol. IPv6 uses 128-bit addresses, theoretically allowing 2128, or approximately 3.4×1038 total addresses.
The actual number is slightly smaller, as multiple ranges are reserved for special use or completely excluded from use. The two protocols are not designed to be interoperable, and thus direct communication between them is impossible, complicating the move to IPv6. However, several transition mechanisms have been devised to rectify this.
IPv6 provides other technical benefits in addition to a larger addressing space. In particular, it permits hierarchical address allocation methods that facilitate route aggregation across the Internet, and thus limit the expansion of routing tables. The use of multicast addressing is expanded and simplified, and provides additional optimization for the delivery of services. Device mobility, security, and configuration aspects have been considered in the design of the protocol.
IPv6 addresses are represented as eight groups of four hexadecimal digits each, separated by colons. The full representation may be shortened; for example, 2001:0db8:0000:0000:0000:8a2e:0370:7334 becomes 2001:db8::8a2e:370:7334. (Source: Wikipedia)
Recommended Online Training: Learn Bash Shell in Linux for Beginners
Linux Server Specification
We have two RHEL 7 virtual machines. for which, we have allocated the following IPv6 addresses.
| Machine | IPv6 Address |
| server1.example.com | fddb:fe2a:ab1e::c0a8:94/64 |
| desktop1.example.com | fddb:fe2a:ab1e::c0a8:95/64 |
| Gateway | fddb:fe2a:ab1e::c0a8:50/64 |
Configure Linux IPv6 Networking
Connect to server1.example.com using ssh and configure IPv6 addresses as follows.
# nmcli connection modify eno16777728 ipv6.method manual ipv6.addresses "fddb:fe2a:ab1e::c0a8:94/64 fddb:fe2a:ab1e::c0a8:50" # nmcli c down eno16777728 ; nmcli c up eno16777728 Connection successfully activated (D-Bus active path: /org/freedesktop/NetworkManager/ActiveConnection/1) # ip addr 1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN
link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
inet 127.0.0.1/8 scope host lo
valid_lft forever preferred_lft forever
inet6 ::1/128 scope host
valid_lft forever preferred_lft forever 2: eno16777728: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP qlen 1000
link/ether 00:0c:29:63:0c:9a brd ff:ff:ff:ff:ff:ff
inet 192.168.116.11/24 brd 192.168.116.255 scope global eno16777728
valid_lft forever preferred_lft forever
inet6 fddb:fe2a:ab1e::c0a8:94/64 scope global
valid_lft forever preferred_lft forever
inet6 fe80::20c:29ff:fe63:c9a/64 scope link
valid_lft forever preferred_lft forever 3: eno33554968: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP qlen 1000
link/ether 00:0c:29:63:0c:a4 brd ff:ff:ff:ff:ff:ff
Now, connect to desktop1.example.com and configure IPv6 network as follows.
# nmcli connection modify eno16777728 ipv6.method manual ipv6.addresses "fddb:fe2a:ab1e::c0a8:95/64 fddb:fe2a:ab1e::c0a8:50"
# nmcli c down eno16777728 ; nmcli c up eno16777728
Connection successfully activated (D-Bus active path: /org/freedesktop/NetworkManager/ActiveConnection/2)
# ip addr
1: lo: mtu 65536 qdisc noqueue state UNKNOWN
link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
inet 127.0.0.1/8 scope host lo
valid_lft forever preferred_lft forever
inet6 ::1/128 scope host
valid_lft forever preferred_lft forever
2: eno16777728: mtu 1500 qdisc pfifo_fast state UP qlen 1000
link/ether 00:0c:29:68:ae:66 brd ff:ff:ff:ff:ff:ff
inet 192.168.116.12/24 brd 192.168.116.255 scope global eno16777728
valid_lft forever preferred_lft forever
inet6 fddb:fe2a:ab1e::c0a8:95/64 scope global
valid_lft forever preferred_lft forever
inet6 fe80::20c:29ff:fe68:ae66/64 scope link
valid_lft forever preferred_lft forever
3: eno33554968: mtu 1500 qdisc pfifo_fast state UP qlen 1000
link/ether 00:0c:29:68:ae:70 brd ff:ff:ff:ff:ff:ffPing both IPv6 addresses from any machine to confirm the network connectivity.
# ping6 fddb:fe2a:ab1e::c0a8:94 PING fddb:fe2a:ab1e::c0a8:94(fddb:fe2a:ab1e::c0a8:94) 56 data bytes 64 bytes from fddb:fe2a:ab1e::c0a8:94: icmp_seq=4 ttl=64 time=0.268 ms 64 bytes from fddb:fe2a:ab1e::c0a8:94: icmp_seq=5 ttl=64 time=0.257 ms ^C --- fddb:fe2a:ab1e::c0a8:94 ping statistics --- 5 packets transmitted, 4 received, 20% packet loss, time 4019ms rtt min/avg/max/mdev = 0.257/0.271/0.299/0.020 ms # ping6 fddb:fe2a:ab1e::c0a8:95 PING fddb:fe2a:ab1e::c0a8:95(fddb:fe2a:ab1e::c0a8:95) 56 data bytes 64 bytes from fddb:fe2a:ab1e::c0a8:95: icmp_seq=2 ttl=64 time=0.056 ms 64 bytes from fddb:fe2a:ab1e::c0a8:95: icmp_seq=3 ttl=64 time=0.060 ms ^C --- fddb:fe2a:ab1e::c0a8:95 ping statistics --- 3 packets transmitted, 3 received, 0% packet loss, time 2002ms rtt min/avg/max/mdev = 0.056/0.062/0.071/0.009 ms
We have successfully configured static IPv6 networking between two Red Hat Enterprise Linux (RHEL) 7 by setting IPv6 addresses using nmcli command.
